Europa Fencing Systems is the premier source for quality fencing products and home improvement financing. At Europa, we proudly stand behind the products we sell, offering one of the highest and longest warranty programs in
the industry.

Experience the classic elegance of our iron, aluminium and wood fencing products without the financial burden. We make financing easy and cheap. Ask us about our flexible financing programs that make it easy
for you to meet your fencing requirements today with small worry free payments for a convenient term of your choice.



OAP1
  SPECIFICATIONS PANEL HEIGHT: UP TO 6FT HIGH 7FT AND HIGHER

POSTS & PICKETS: EXTRUDED MARINE ALUMINUM 6061-T6
PRIME ALUMINIUM, NORTH AMERICAN PRODUCED

FINISH:SEVEN STAGE ARCHITECTURALLY CERTIFIED PRETREATMENT AS PER AAMA 2604. SUPER DURABLE ELECTROSTATICALLY APPLIED POWDER COAT - MIN THICKNESS 2.5mils

POSTS: 76mm x 76mm (3"x3") .188 WALL OPTION: 102mm x 102mm (4"x4") .188 WALL
POST FLANGES: 152mm x 152mm x 6mm (6" x6" x1/2") or 203mm x 203mm x13mm (8"x8"x1/2")

POST CAPS: PYRAMID or BALL

RAILS: 38mm x 64mm (11/2" x 21/2") .120 WALL

PICKETS: 25mm x 25mm (1"x1") .065 WALL SPEAR (SP-9Z), FLEUR DE LIS (SP-7Z) ARROW, FLAT, OR SECURITY TOP (USE SPEAR SP-9Z UNLESS OTHERWISE NOTED)

PANEL WIDTH 953/4" (2432mm), 671/4" (1708)

POST CENTERS: 101"(2565mm), 721/2" (1842mm)

FITTINGS: 12GA, STAMPED MARINE GRADE ALUMINUM FINISH AS DESCRIBED

WELDS: ALUMINUM - FULL BEAD ON PUBLIC SIDE - TACK WELD ON PRIVATE SIDE

COLOUR: STANDARD COLOURS ARE BLACK, SEMI-BLACK BROWN, GREEN, WHITE AND FOREST GREEN

WARRANTY: 20 YEAR LIMITED


OA-FSDB1
  SPECIFICATIONS PANEL HEIGHT: UP TO 6FT HIGH 7FT AND HIGHER

POSTS & PICKETS: EXTRUDED MARINE ALUMINUM 6061-T6
PRIME ALUMINIUM, NORTH AMERICAN PRODUCED

FINISH:SEVEN STAGE ARCHITECTURALLY CERTIFIED PRETREATMENT AS PER AAMA 2604. SUPER DURABLE ELECTROSTATICALLY APPLIED POWDER COAT - MIN THICKNESS 2.5mils

POSTS: 76mm x 76mm (3"x3") .188 WALL OPTION: 102mm x 102mm (4"x4") .188 WALL
POST FLANGES: 152mm x 152mm x 6mm (6" x6" x1/2") or 203mm x 203mm x13mm (8"x8"x1/2")

POST CAPS: PYRAMID or BALL

RAILS: 38mm x 64mm (11/2" x 21/2") .120 WALL

PICKETS: 25mm x 25mm (1"x1") .065 WALL SPEAR (SP-9Z), FLEUR DE LIS (SP-7Z) ARROW, FLAT, OR SECURITY TOP (USE SPEAR SP-9Z UNLESS OTHERWISE NOTED)

PANEL WIDTH 953/4" (2432mm), 671/4" (1708)

POST CENTERS: 101"(2565mm), 721/2" (1842mm)

FITTINGS: 12GA, STAMPED MARINE GRADE ALUMINUM FINISH AS DESCRIBED

WELDS: ALUMINUM - FULL BEAD ON PUBLIC SIDE - TACK WELD ON PRIVATE SIDE

COLOUR: STANDARD COLOURS ARE BLACK, SEMI-BLACK BROWN, GREEN, WHITE AND FOREST GREEN

WARRANTY: 20 YEAR LIMITED


OMG-A-DBPF1
  SPECIFICATIONS PANEL HEIGHT: UP TO 6FT HIGH 7FT AND HIGHER

POSTS & PICKETS: EXTRUDED MARINE ALUMINUM 6061-T6
PRIME ALUMINIUM, NORTH AMERICAN PRODUCED

FINISH:SEVEN STAGE ARCHITECTURALLY CERTIFIED PRETREATMENT AS PER AAMA 2604. SUPER DURABLE ELECTROSTATICALLY APPLIED POWDER COAT - MIN THICKNESS 2.5mils

POSTS: 76mm x 76mm (3"x3") .188 WALL OPTION: 102mm x 102mm (4"x4") .188 WALL
POST FLANGES: 152mm x 152mm x 6mm (6" x6" x1/2") or 203mm x 203mm x13mm (8"x8"x1/2")

POST CAPS: PYRAMID or BALL

RAILS: 38mm x 64mm (11/2" x 21/2") .120 WALL

PICKETS: 25mm x 25mm (1"x1") .065 WALL SPEAR (SP-9Z), FLEUR DE LIS (SP-7Z) ARROW, FLAT, OR SECURITY TOP (USE SPEAR SP-9Z UNLESS OTHERWISE NOTED)

PANEL WIDTH 953/4" (2432mm), 671/4" (1708)

POST CENTERS: 101"(2565mm), 721/2" (1842mm)

FITTINGS: 12GA, STAMPED MARINE GRADE ALUMINUM FINISH AS DESCRIBED

WELDS: ALUMINUM - FULL BEAD ON PUBLIC SIDE - TACK WELD ON PRIVATE SIDE

COLOUR: STANDARD COLOURS ARE BLACK, SEMI-BLACK BROWN, GREEN, WHITE AND FOREST GREEN

WARRANTY: 20 YEAR LIMITED


OA-DBPF2
  SPECIFICATIONS PANEL HEIGHT: UP TO 6FT HIGH 7FT AND HIGHER

POSTS & PICKETS: EXTRUDED MARINE ALUMINUM 6061-T6
PRIME ALUMINIUM, NORTH AMERICAN PRODUCED

FINISH:SEVEN STAGE ARCHITECTURALLY CERTIFIED PRETREATMENT AS PER AAMA 2604. SUPER DURABLE ELECTROSTATICALLY APPLIED POWDER COAT - MIN THICKNESS 2.5mils

POSTS: 76mm x 76mm (3"x3") .188 WALL OPTION: 102mm x 102mm (4"x4") .188 WALL
POST FLANGES: 152mm x 152mm x 6mm (6" x6" x1/2") or 203mm x 203mm x13mm (8"x8"x1/2")

POST CAPS: PYRAMID or BALL

RAILS: 38mm x 64mm (11/2" x 21/2") .120 WALL

PICKETS: 25mm x 25mm (1"x1") .065 WALL SPEAR (SP-9Z), FLEUR DE LIS (SP-7Z) ARROW, FLAT, OR SECURITY TOP (USE SPEAR SP-9Z UNLESS OTHERWISE NOTED)

PANEL WIDTH 953/4" (2432mm), 671/4" (1708)

POST CENTERS: 101"(2565mm), 721/2" (1842mm)

FITTINGS: 12GA, STAMPED MARINE GRADE ALUMINUM FINISH AS DESCRIBED

WELDS: ALUMINUM - FULL BEAD ON PUBLIC SIDE - TACK WELD ON PRIVATE SIDE

COLOUR: STANDARD COLOURS ARE BLACK, SEMI-BLACK BROWN, GREEN, WHITE AND FOREST GREEN

WARRANTY: 20 YEAR LIMITED


OA-RDBPF3
  SPECIFICATIONS PANEL HEIGHT: UP TO 6FT HIGH 7FT AND HIGHER

POSTS & PICKETS: EXTRUDED MARINE ALUMINUM 6061-T6
PRIME ALUMINIUM, NORTH AMERICAN PRODUCED

FINISH:SEVEN STAGE ARCHITECTURALLY CERTIFIED PRETREATMENT AS PER AAMA 2604. SUPER DURABLE ELECTROSTATICALLY APPLIED POWDER COAT - MIN THICKNESS 2.5mils

POSTS: 76mm x 76mm (3"x3") .188 WALL OPTION: 102mm x 102mm (4"x4") .188 WALL
POST FLANGES: 152mm x 152mm x 6mm (6" x6" x1/2") or 203mm x 203mm x13mm (8"x8"x1/2")

POST CAPS: PYRAMID or BALL

RAILS: 38mm x 64mm (11/2" x 21/2") .120 WALL

PICKETS: 25mm x 25mm (1"x1") .065 WALL SPEAR (SP-9Z), FLEUR DE LIS (SP-7Z) ARROW, FLAT, OR SECURITY TOP (USE SPEAR SP-9Z UNLESS OTHERWISE NOTED)

PANEL WIDTH 953/4" (2432mm), 671/4" (1708)

POST CENTERS: 101"(2565mm), 721/2" (1842mm)

FITTINGS: 12GA, STAMPED MARINE GRADE ALUMINUM FINISH AS DESCRIBED

WELDS: ALUMINUM - FULL BEAD ON PUBLIC SIDE - TACK WELD ON PRIVATE SIDE

COLOUR: STANDARD COLOURS ARE BLACK, SEMI-BLACK BROWN, GREEN, WHITE AND FOREST GREEN

WARRANTY: 20 YEAR LIMITED


OA-DB (Butterfly & Flower) Gate


OA-DB Gate


OA-DB (Butterfly & Flower) Semi-Private Gate
